Carbon Steel 2:1 Ellipsoidal Heads Customized By Spinning Process Or Pressing

Carbon Steel 2:1 Ellipsoidal Heads Customized By Spinning Process Or Pressing
Carbon Steel 2:1 Ellipsoidal Heads Customized By Spinning Process Or Pressing

Large Image :  Carbon Steel 2:1 Ellipsoidal Heads Customized By Spinning Process Or Pressing

Product Details:
Place of Origin: China
Brand Name: GLM
Certification: ASMEU,R,U2,PED,ABS,TUV,NB,ISO,
Model Number: Cap
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: $25-125
Packaging Details: Wooden cases ,wooden pallet,Steel pallet or as per customers requirement
Delivery Time: 10-30
Payment Terms: L/C,Western Union,T/T
Supply Ability: 50000 pieces per Month

Carbon Steel 2:1 Ellipsoidal Heads Customized By Spinning Process Or Pressing

Description
Forming Method: Hot Forming,cold Forming Connection: Welding
Thickness: 3-300mm Surface Treatment: Sand Blasting, Pickling, Oil, Discaling
Application: Storage Tanks, Boilers And Other Equipment Diameter: 89-1000mm
Applicable Standard: ASME ,PED And GB Shape: Dished Heads
High Light:

2:1 Ellipsoidal Heads

,

Carbon Steel Ellipsoidal Heads

,

Spinning Process Elliptical Dished Ends

Carbon Steel 2:1 Ellipsoidal Heads Customized By Spinning Process Or Pressing

Product Description:

Carbon Steel Dished Heads are commonly used for storage tanks, boilers and other equipment. These heads can be formed by either hot forming or cold forming. Hot forming is responsible for forming thicker products whereas cold forming is used for thinner products. Carbon steel dished heads are available in thicknesses ranging from 3mm to 300mm. The connection of these heads is usually done through welding. They are inspected through UT, RT, MT, PT and TOFD tests to ensure the quality of the product. Carbon steel dished heads are mainly used for 2:1 Ellipsoidal Heads, Ellipsoidal Dish Head and Hemispherical Dish End.



Features:

  • Product Name: Carbon Steel Dished Heads
  • Inspection: UT,RT,MT,PT,TOFD
  • Shape: Toriconical Cone, Hemispherical dish end, Hemispherical dish end, Ellipsoidal dish end, Dish end with flange
  • Packaging: Wooden Cases ,wooden Pallet,Steel Pallet Or As Per Customers Requirement
  • Processing Method: Spinning Process Or Pressing
  • Surface Treatment: Sand Blasting, Pickling, Oil, Discaling


Technical Parameters:

Property Value
Diameter 89-1000mm
Technology Stamping
Applicable Standard ASME, PED and GB
Application Storage Tanks, Boilers and other Equipment
Inspection UT,RT,MT,PT,TOFD
Material Carbon Steel, Stainless Steel, Aluminum, Nickel etc.
Radius Customers' Requirement
Thickness 3-300mm
Connection Welding
Surface Treatment Sand Blasting, Pickling, Oil, Discaling
Special Focus ASME code heads, Ellipsoidal Dish Head, Conical Dish Heads, Hemispherical Dish Heads


Applications:

Dished heads are used in a variety of applications, including pressure vessels, process columns, domed roofs for large storage tanks, vacuum chambers, wear plates and liners. These tank heads are made from steel and are formed by cold press forming or hot spinning


Customization:

Carbon Steel Dished Heads
Brand Name: GLM
Model Number: Cap
Place of Origin: China
Certification: ASMEU,R,U2,PED,ABS,TUV,NB,ISO
Minimum Order Quantity: 1
Price: $25-125
Packaging Details: Wooden cases ,wooden pallet,Steel pallet or as per customers requirement
Delivery Time: 10-30
Payment Terms: L/C,Western Union,T/T
Supply Ability: 50000 pieces per Month
Surface Treatment: Sand Blasting, Pickling, Oil, Discaling
Processing Method: Spinning Process Or Pressing
Diameter: 89-1000mm
Technolog: Stamping
Connection: Welding
GLM Carbon Steel Dished Heads are specialized for a variety of applications. Our range of 2:1 Ellipsoidal Heads, Segmented Tank Heads, Toriconical Cone Heads, Hemispherical Heads, Flat Heads, Flanged-Only Heads, 80:10 Toriconical Cone Heads are designed to meet the unique needs of each customer. The products have a wide range of sizes and diameters, from 89-1000 mm. Our advanced stamping technology provides superior performance and ensures that the products always meet the highest quality standards. The surface treatment of the products is Sand Blasting, Pickling, Oil, Discaling. We accept custom orders and provide top-notch customer service. Contact us today for reliable Carbon Steel Dished Heads.

Support and Services:

At XXXXXX, we are committed to providing our customers with the highest quality Carbon Steel Dished Heads and the best technical support and service. Our team of experienced engineers is available to provide assistance and advice during the product selection process, as well as after-sales support and maintenance. We also offer a range of custom fabrication services, including cutting, welding, machining, and heat treating, to ensure that each product meets customer specifications. Our commitment to quality and satisfaction is our guarantee to our customers.

Carbon Steel 2:1 Ellipsoidal Heads Customized By Spinning Process Or Pressing 0Carbon Steel 2:1 Ellipsoidal Heads Customized By Spinning Process Or Pressing 1Carbon Steel 2:1 Ellipsoidal Heads Customized By Spinning Process Or Pressing 2Carbon Steel 2:1 Ellipsoidal Heads Customized By Spinning Process Or Pressing 3
