Carbon Steel Elliptical Tank Heads 1268mm Diameter 16mm Thickness
Product Details
| Name: | Carbon Steel Tank Heads | Specifications: | HHA,EHA,THA Or Customized |
|---|---|---|---|
| Surface: | Bare,sandblasting | Materail: | Carbon Steel |
| Application: | Offshore , Cryogenic Industry | Technology: | Stamping |
| Diameter: | 1268mm | Thickness: | 16mm |
| Keywords: | Elliptical Heads | Connection: | Welding |
| Highlight |
Elliptical Carbon Steel Tank Heads,Carbon Steel Elliptical Tank Heads,16mm Elliptical Tank Heads |
||
Product Description
Carbon Steel tank Heads,elliptical Heads 1268mm Diameter 16mm Thickness
Description of dish head
Materials: SA516Gr70
Size : 1268mm diameter x 16 mm thickness
Applications: Our business focus is Oil & Gas, Refinery. Petrochemical and Power Industry.
Types of Pressure Vessels Heads :
There are four basic types of pressure vessels heads or Dish ends is most widely used in fabrication of Pressure Vessels.
1. Ellipsoidal Heads
2. Hemipherical Heads
3. Flat Heads
4. Toripherical Heads or Flange and Dished Heads
5. spherical heads
6. cone
Specifications of elliptical heads
| Brand Name: | GLM |
| Diameter: | 89mm--10000mm |
| Thickness: | 2mm--300mm |
| Reduction Ratio: | about 10% |
| Material: | Carbon Steel, Stainless Steel, Duplex, Super Duplex, Aluminum, Nickel and Nickel Alloys, Copper and Copper Alloys, Titanium and Its Alloys, Zirconium and all cladded material combinations. |
| Forming method: | Hot forming,cold forming |
| Surface Treatment: | Sand Blasting,Pickling,oil,discaling |
| Inspection: | UT,RT,MT,PT,TOFD. |
| Applicable Standard: | ASME ,PED and GB |
| Certificate: | ISO9001,ISO45001,OHSAS18001 |
| Applications: |
Such as oil, chemical industry, water conservancy, electric power, boiler, machinery, metallurgy, sanitary construction etc. |
| Package: | Wooden cases ,wooden pallet,Steel pallet or as per customers requirement |
| Customized Product: | Available |
Products of tank heads
FAQ:
1. What’s the information should I provide when inquiry?
Thanks for your question. If you have drawings, we will be entirely in accordance with production drawings . If you do not have the drawing, you can tell me the product data. There are several important data, such as material, type of head( We have elliptical head, hemispherical head, dished head, flat head, etc. ),diameter, thickness, special tolerances or requirements. We can do the drawings according to your requirements, and you confirm that the final product drawings.
2. what are surface treatment of the product?
Thanks for your question. For carbon steel products, we sandblasting descaling product surface. For stainless steel products, we use acid to remove surface oil and impurities.
3. How do you ensure the quality of products?
Thanks for your question.Our production staff is trained through national quality department, and obtain the corresponding certificate, with years of production and design experience. Weld must undergo X-ray inspection to ensure that no defects.
4. Can you help us matching related products?
Thanks for your question. Our company also is surrounded by a lot of ancillary businesses, such as flanges, boiler, oil refining equipment, etc. We can help you matching the highest quality products with the lowest prices.
