Customized Carbon Steel Elliptical Dished Head For Pressure Vessel

Large Image : Customized Carbon Steel Elliptical Dished Head For Pressure Vessel

Product Details:

Place of Origin:	China
Brand Name:	GLM
Certification:	ASME, PED and GB
Model Number:	CAP

Payment & Shipping Terms:

Minimum Order Quantity:	1
Packaging Details:	wooden box and iron shelf or as percustomers requirement
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	50000

Contact Now

Customized Carbon Steel Elliptical Dished Head For Pressure Vessel

Description

General:	Carbon Steel Elliptical Dished Head	Diameter:	2286mm
Material:	SA516 Gr.70N	Head Shape:	Round
Thickness:	30mm	Keyword:	Ellipsoidal Dished Head
Technic:	Forged /cold Formed /hot Pressing	Reduction Ratio:	About 10%
Certificate:	ISO 9001	OEM:	Avaiable
Highlight:	Customized Elliptical Dished Head , Pressure Vessel Elliptical Dished Head , Forged Carbon Steel Dished Heads

Customized Carbon Steel Elliptical Dished Head used for Pressure Vessel

Description of Ellipsoidal Dished Head:

The ASME Section VIII-Division 1 determines the rules for dished heads. The most common configurations are ellipsoidal head 2:1 ,torispherical dished end,hemispherical dish cap , spherical head ,cones,flat dish head. How the shapes are ,make some confusion for beginners and even professionals users of ASME Section VIII .

Specifications of Carbon steel dished head:

Brand Name:	GLM
Diameter:	89mm--10000mm
Thickness:	2mm--300mm
Reduction Ratio:	about 10%
Material:	Carbon Steel, Stainless Steel, Duplex, Super Duplex, Aluminum, Nickel and Nickel Alloys, Copper and Copper Alloys, Titanium and Its Alloys, Zirconium and all cladded material combinations.
Forming method:	Hot forming,cold forming
Surface Treatment:	Sand Blasting,Pickling,oil,discaling
Inspection:	UT,RT,MT,PT,TOFD.
Applicable Standard:	ASME ,PED and GB
Certificate:	ISO9001,ISO45001,OHSAS18001
Applications:	Such as oil, chemical industry, water conservancy, electric power, boiler, machinery, metallurgy, sanitary construction etc.
Package:	Wooden cases ,wooden pallet,Steel pallet or as per customers requirement
Customized Product:	Available

Products of pressure vessel head

Customized Carbon Steel Elliptical Dished Head For Pressure Vessel 0

Customized Carbon Steel Elliptical Dished Head For Pressure Vessel 2

Equipment of hot forming head:

Customized Carbon Steel Elliptical Dished Head For Pressure Vessel 4

Customized Carbon Steel Elliptical Dished Head For Pressure Vessel 5

Customized Carbon Steel Elliptical Dished Head For Pressure Vessel 6
