1190mm Dia Hemispherical Head A516gr70 135mm Thickness

1190mm Dia Hemispherical Head A516gr70 135mm Thickness
1190mm Dia Hemispherical Head A516gr70 135mm Thickness

Large Image :  1190mm Dia Hemispherical Head A516gr70 135mm Thickness

Product Details:
Place of Origin: China
Brand Name: GLM
Certification: ASME, PED and GB
Model Number: CAP
Payment & Shipping Terms:
Minimum Order Quantity: 1
Packaging Details: wooden box and iron shelf or as percustomers requirement
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram

1190mm Dia Hemispherical Head A516gr70 135mm Thickness

Description
Name: Hemispherical Head A516gr70 Specifications: HHA,EHA,THA Or Customized
Surface: Bare,sandblasting Materail: A516GR70
Application: Offshore , Cryogenic Industry Technology: Stamping
Diameter: 1190mm Minimum Wall Thickness: 135mm
Keywords: Hemishpreical Bottom,dish Head Connection: Welding
High Light:

A516gr70 Hemispherical Head

,

135mm Hemispherical Head

,

1190mm Hemispherical Tank Heads

1190mmmm Dia Hemispherical Head A516gr70 135mm Thickness



Description of Hemishpherical Head A516gr70

Hemispherical Head A516gr70 After form thk.=135 ID= 1190mm SF=75mm Ho= 595 mm QTY4



Torispherical head
These heads have a dish with a fixed radius (CR), the size of which depends on the type of torispherical head. The transition between the cylinder and the dish is called the knuckle. The knuckle has a toroidal shape.



Specifications of Hemispherical dish head:



Brand Name: GLM
Diameter: 89mm--10000mm
Thickness: 2mm--300mm
Reduction Ratio: about 10%
Material: Carbon Steel, Stainless Steel, Duplex, Super Duplex, Aluminum, Nickel and Nickel Alloys, Copper and Copper Alloys, Titanium and Its Alloys, Zirconium and all cladded material combinations.
Forming method: Hot forming,cold forming
Surface Treatment: Sand Blasting,Pickling,oil,discaling
Inspection: UT,RT,MT,PT,TOFD.
Applicable Standard: ASME ,PED and GB
Certificate: ISO9001,ISO45001,OHSAS18001
Applications:

Such as oil, chemical industry, water conservancy, electric power,

boiler, machinery, metallurgy, sanitary construction etc.

Package: Wooden cases ,wooden pallet,Steel pallet or as per customers requirement
Customized Product: Available





Products of Hemispherical Dished heads

1190mm Dia Hemispherical Head A516gr70 135mm Thickness 01190mm Dia Hemispherical Head A516gr70 135mm Thickness 1

1190mm Dia Hemispherical Head A516gr70 135mm Thickness 21190mm Dia Hemispherical Head A516gr70 135mm Thickness 3



FAQ:

1. What’s the information should I provide when inquiry?

Thanks for your question. If you have drawings, we will be entirely in accordance with production drawings . If you do not have the drawing, you can tell me the product data. There are several important data, such as material, type of head( We have elliptical head, hemispherical head, dished head, flat head, etc. ),diameter, thickness, special tolerances or requirements. We can do the drawings according to your requirements, and you confirm that the final product drawings.



2. what are surface treatment of the product?

Thanks for your question. For carbon steel products, we sandblasting descaling product surface. For stainless steel products, we use acid to remove surface oil and impurities.



3. How do you ensure the quality of products?

Thanks for your question.Our production staff is trained through national quality department, and obtain the corresponding certificate, with years of production and design experience. Weld must undergo X-ray inspection to ensure that no defects.



4. Can you help us matching related products?

Thanks for your question. Our company also is surrounded by a lot of ancillary businesses, such as flanges, boiler, oil refining equipment, etc. We can help you matching the highest quality products with the lowest prices.
