ASME Pressure Vessel Boiler Part Steel Torispherical Head Dish End

Certification
China Wuhan Linmei Head Plate Co., Ltd. certification
China Wuhan Linmei Head Plate Co., Ltd. certification
I'm Online Chat Now

ASME Pressure Vessel Boiler Part Steel Torispherical Head Dish End

ASME Pressure Vessel Boiler Part Steel Torispherical Head Dish End
ASME Pressure Vessel Boiler Part Steel Torispherical Head Dish End

Large Image :  ASME Pressure Vessel Boiler Part Steel Torispherical Head Dish End

Product Details:
Place of Origin: China
Brand Name: GLM
Certification: ASME, PED and GB
Model Number: CAP
Payment & Shipping Terms:
Minimum Order Quantity: 1
Packaging Details: wooden box and iron shelf or as percustomers requirement
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 50000

ASME Pressure Vessel Boiler Part Steel Torispherical Head Dish End

Description
General: Torisperical Head Dish End Material: SA516GR70
Industry Focus: Chemistry, Petro-chemistry, Food, Medicine, Fisher Type: Cap
Connection: Welding Shape: Reducing
Technics: Hot Pressing Surface Treatment: Hot Galvanized
Head Code: Torispherical End
High Light:

Steel Torispherical Head Dish End

,

ASME Torispherical Head Dish End

,

Boiler Torispherical Dished Head

ASME Pressure vessel boiler part steel torisperical head dish end

Steel Torispherical dish ends are required in a wide range of processing industries to ensure safety and quality standards are a top priority. Many carbon steel,stainless steel tank fabricators are asked to build storage vessels every day. We fabricate ASME dish heads that will meet the needs of your business and your customer.



Forming method:cold and hot pressing,cold and hot spinning,punching



Application:Our different material and specification heads can be used in many fileds,such as petroleum,chemistry, petro-chemistry, food, medicine, fisher,boiler,pressure vessels,railway transportation,metal structure,water supply facilities and aerospace engineering,etc.





Specifications of torispherical dished end:



Brand Name: GLM
Diameter: 89mm--10000mm
Thickness: 2mm--300mm
Reduction Ratio: about 10%
Material: Carbon Steel, Stainless Steel, Duplex, Super Duplex, Aluminum, Nickel and Nickel Alloys, Copper and Copper Alloys, Titanium and Its Alloys, Zirconium and all cladded material combinations.
Forming method: Hot forming,cold forming
Surface Treatment: Sand Blasting,Pickling,oil,discaling
Inspection: UT,RT,MT,PT,TOFD.
Applicable Standard: ASME ,PED and GB
Certificate: ISO9001,ISO45001,OHSAS18001
Applications:

Such as oil, chemical industry, water conservancy, electric power,

boiler, machinery, metallurgy, sanitary construction etc.

Package: Wooden cases ,wooden pallet,Steel pallet or as per customers requirement
Customized Product: Available





Product Display of Steel Torispherical Dished Head



ASME Pressure Vessel Boiler Part Steel Torispherical Head Dish End 0

ASME Pressure Vessel Boiler Part Steel Torispherical Head Dish End 1ASME Pressure Vessel Boiler Part Steel Torispherical Head Dish End 2



Our company



ASME Pressure Vessel Boiler Part Steel Torispherical Head Dish End 3ASME Pressure Vessel Boiler Part Steel Torispherical Head Dish End 4

ASME Pressure Vessel Boiler Part Steel Torispherical Head Dish End 5

ASME Pressure Vessel Boiler Part Steel Torispherical Head Dish End 6
