7600mm Diameter Custom Dish Heads 23mm Thickness Elliptical Dished Head
Product Details
| Material: | SA516 GR70N | Head Code: | Elliptical Dished Head |
|---|---|---|---|
| Test: | UT,RT,MT,PT | Mfg Process: | Cold Press |
| Application: | Oil, Gas, Steam Etc. | Keywords: | Dish Heads |
| Diameter: | 7600mm | Thickness: | 23mm |
| Highlight |
7600mm Diameter Custom Dish Heads,23mm Custom Dish Heads,SA516 Elliptical Dished Head |
||
Product Description
7600mm Diameter Custom dish heads 23mm thickness elliptical dished head
Description of dish heads
dish head has an elliptical shape and the most popular ratio is 2:1 (which means that the width of the ellipse is double the depth). When it comes to handling pressure stresses, elliptical dished head is less efficient than a hemispherical tank head, so ASME specifications require increased thickness.
Specifications of dish end:
| Brand Name: | GLM |
| Diameter: | 89mm--10000mm |
| Thickness: | 2mm--300mm |
| Reduction Ratio: | about 10% |
| Material: | Carbon Steel, Stainless Steel, Duplex, Super Duplex, Aluminum, Nickel and Nickel Alloys, Copper and Copper Alloys, Titanium and Its Alloys, Zirconium and all cladded material combinations. |
| Forming method: | Hot forming,cold forming |
| Surface Treatment: | Sand Blasting,Pickling,oil,discaling |
| Inspection: | UT,RT,MT,PT,TOFD. |
| Applicable Standard: | ASME ,PED and GB |
| Certificate: | ISO9001,ISO45001,OHSAS18001 |
| Applications: |
Such as oil, chemical industry, water conservancy, electric power, boiler, machinery, metallurgy, sanitary construction etc. |
| Package: | Wooden cases ,wooden pallet,Steel pallet or as per customers requirement |
| Customized Product: | Available |
Item Process of dish head
| 1. | picking steel | 2. | cutting | 3. | welding | 4. | heating |
| 5. | stamping | 6. | spinning | 7. | trimming | 8. | defect dection |
| 9. | QC | 10. | warehousing | 11. | transportation |
Products of elliptical head
Our Company
Our main products are Dish Head,Hemispherical head,Spherical head,Elliptical head,Conical head,Flat head,etc,available with different kinds of material and OEM service.The certificate we obtained are ISO9001,ISO14001,OHSAS18001 and ASME.
With 40000 square meter workshops,200employees,20years accumulated experience,advanced technologies and equipments,we always support our customers with best quality&best service and fast delivery.We warmly welcome to your visiting of our factory.
FAQ
Q: Are you trading company or manufacturer ?
A: We are factory.
Q: How long is your delivery time?
A: Generally it is 7-20 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge if we have stock but do not pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact us as below:
