Stainless Steel 2: 1 Ellipsoidal Dished End For Reactor Vessels

Stainless Steel 2: 1 Ellipsoidal Dished End For Reactor Vessels
Stainless Steel 2: 1 Ellipsoidal Dished End For Reactor Vessels

Large Image :  Stainless Steel 2: 1 Ellipsoidal Dished End For Reactor Vessels

Product Details:
Place of Origin: China
Brand Name: GLM
Certification: ASME, PED and GB
Model Number: CAP
Payment & Shipping Terms:
Minimum Order Quantity: 1
Packaging Details: wooden box and iron shelf or as percustomers requirement
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 50000

Stainless Steel 2: 1 Ellipsoidal Dished End For Reactor Vessels

Description
General: 2: 1 Ellipsoidal Dished End Diameter: 3500mm
Material: Stainless Steel 316l Head Shape: Round
Color: Customer's Request Reduction Ratio: About 10%
Thickness: 10mm Forming Method: Hot Forming
Applications: SLURRY TANK Applicable Standard: ASME
High Light:

2: 1 Ellipsoidal Dished End

,

Stainless Steel Ellipsoidal Dished End

,

Reactor Vessels Semi Elliptical Head

Stainless Steel 2: 1 Ellipsoidal Dished End For Reactor Vessels



Description:



2:1 Ellipsoidal dished end:



2:1 Ellipsoidal dished ends are deeper and stronger than the more popular torispherical dished heads. The greater depth results in the head being more difficult to form, and this makes them more expensive to manufacture. However, the cost is offset by a potential reduction in the specified thickness due to the dished end having greater overall strength and resistance to pressure.



Process type: cold pressing,hot pressing,cold spinning ,segment,etc





Specifications Of Stainless steel 2:1 elliptical head:



Brand Name: GLM
Diameter: 89mm--10000mm
Thickness: 2mm--300mm
Reduction Ratio: about 10%
Material: Carbon Steel, Stainless Steel, Duplex, Super Duplex, Aluminum, Nickel and Nickel Alloys, Copper and Copper Alloys, Titanium and Its Alloys, Zirconium and all cladded material combinations.
Forming method: Hot forming,cold forming
Surface Treatment: Sand Blasting,Pickling,oil,discaling
Inspection: UT,RT,MT,PT,TOFD.
Applicable Standard: ASME ,PED and GB
Certificate: ISO9001,ISO45001,OHSAS18001
Applications:

Such as oil, chemical industry, water conservancy, electric power,

boiler, machinery, metallurgy, sanitary construction etc.

Package: Wooden cases ,wooden pallet,Steel pallet or as per customers requirement
Customized Product: Available





Products of asme ellipsoidal dished end



Stainless Steel 2: 1 Ellipsoidal Dished End For Reactor Vessels 0

Stainless Steel 2: 1 Ellipsoidal Dished End For Reactor Vessels 1Stainless Steel 2: 1 Ellipsoidal Dished End For Reactor Vessels 2



Equipment of dished end:



Stainless Steel 2: 1 Ellipsoidal Dished End For Reactor Vessels 3Stainless Steel 2: 1 Ellipsoidal Dished End For Reactor Vessels 4

Stainless Steel 2: 1 Ellipsoidal Dished End For Reactor Vessels 5
