ASME Custom Elliptical Head 2:1 Cold Spinning Dished Heads

ASME Custom Elliptical Head 2:1 Cold Spinning Dished Heads
ASME Custom Elliptical Head 2:1 Cold Spinning Dished Heads

Large Image :  ASME Custom Elliptical Head 2:1 Cold Spinning Dished Heads

Product Details:
Place of Origin: China
Brand Name: GLM
Certification: ASME, PED and GB
Model Number: CAP
Payment & Shipping Terms:
Minimum Order Quantity: 1
Packaging Details: wooden box and iron shelf or as percustomers requirement
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 50000

ASME Custom Elliptical Head 2:1 Cold Spinning Dished Heads

Description
Head Code: Elliptical Head 2:1 ASME Diameter: 2800mm
Shape:: Equal Material: Carbon Steel
Standard:: ANSI, ASME ,MSS Usage:: Convey Water, Oil, Gas, Steam And So On
Thinckness: 10mm Forming Method: Cold Forming
Applications: Water Conservancy,chemical Industry Inspection: UT
High Light:

ASME Custom Elliptical Head

,

Cold Spinning Custom Elliptical Head

,

2:1 Cold Spinning Dished Heads

Custom elliptical head 2:1 ASME and Cold Spinning Dished heads



Dished heads is major Part of Pressure Vessel which closes ends of the cylindrical section or shell of the pressure vessel is called as elliptical Heads. There are various common names are used for ASME Elliptical head which are Dish heads, Formed Heads, dish end, semi elliptical heads, Vessel Ends, Flat Dish heads etc. but most Common name is Dish ends.





elliptical head 2:1 ASME:

elliptical head 2:1 ASME is a most widely used storage. It has wider Radial section is available for pressure distribution.it with stand maximum pressure as compared to other heads. So it is most preferred hemispheres tank ends. for same design condition, Dish end Thickness of ellipsoidal heads is approximately equals to shell thickness so it is most economical heads. Generally most used Ellipsoidal Heads Configuration is as per 2:1 Ellipsoidal Section.



Specifications of elliptical head 2:1 ASME :



Brand Name: GLM
Diameter: 89mm--10000mm
Thickness: 2mm--300mm
Reduction Ratio: about 10%
Material: Carbon Steel, Stainless Steel, Duplex, Super Duplex, Aluminum, Nickel and Nickel Alloys, Copper and Copper Alloys, Titanium and Its Alloys, Zirconium and all cladded material combinations.
Forming method: Hot forming,cold forming
Surface Treatment: Sand Blasting,Pickling,oil,discaling
Inspection: UT,RT,MT,PT,TOFD.
Applicable Standard: ASME ,PED and GB
Certificate: ISO9001,ISO45001,OHSAS18001
Applications:

Such as oil, chemical industry, water conservancy, electric power,

boiler, machinery, metallurgy, sanitary construction etc.

Package: Wooden cases ,wooden pallet,Steel pallet or as per customers requirement
Customized Product: Available





Products of Custom elliptical head 2:1 ASME



ASME Custom Elliptical Head 2:1 Cold Spinning Dished Heads 0

ASME Custom Elliptical Head 2:1 Cold Spinning Dished Heads 1

ASME Custom Elliptical Head 2:1 Cold Spinning Dished Heads 2



producing-process mode

ASME Custom Elliptical Head 2:1 Cold Spinning Dished Heads 3
