Carbon Steel Dish Tank Head For Dyeing And Drying Yarns
Product Details
| Material: | Carbon Steel, Stainless Steel, Duplex | Forming Method: | Hot Forming,cold Forming |
|---|---|---|---|
| Applicable Standard: | ASME ,PED And GB | Keyword: | Dished End |
| Application:: | Pulp & Paper , Mining | Other Product: | Cylindrical Shell |
| Highlight |
Carbon Steel Dish Tank Head,Dyeing Dish Tank Head,Drying Yarns Dished Tank Heads |
||
Product Description
Dish tank head for impianti completi per la tintura e l’essiccazione dei filati
We manufacture a wide range of vessel heads to works standards, both for construction purposes and as dished vessel heads in the form of torispherical heads, elliptical heads and caps for pressure applications.
Specifications:
| Brand Name: | GLM |
| Diameter: | 89mm--10000mm |
| Thickness: | 2mm--300mm |
| Reduction Ratio: | about 10% |
| Material: | Carbon Steel, Stainless Steel, Duplex, Super Duplex, Aluminum, Nickel and Nickel Alloys, Copper and Copper Alloys, Titanium and Its Alloys, Zirconium and all cladded material combinations. |
| Forming method: | Hot forming,cold forming |
| Surface Treatment: | Sand Blasting,Pickling,oil,discaling |
| Inspection: | UT,RT,MT,PT,TOFD. |
| Applicable Standard: | ASME ,PED and GB |
| Certificate: | ISO9001,ISO45001,OHSAS18001 |
| Applications: |
Such as oil, chemical industry, water conservancy, electric power, boiler, machinery, metallurgy, sanitary construction etc. |
| Package: | Wooden cases ,wooden pallet,Steel pallet or as per customers requirement |
| Customized Product: | Available |
Products
FAQ:
1. What’s the information should I provide when inquiry?
Thanks for your question. If you have drawings, we will be entirely in accordance with production drawings . If you do not have the drawing, you can tell me the product data. There are several important data, such as material, type of head( We have elliptical head, hemispherical head, dished head, flat head, etc. ),diameter, thickness, special tolerances or requirements. We can do the drawings according to your requirements, and you confirm that the final product drawings.
2. what are surface treatment of the product?
Thanks for your question. For carbon steel products, we sandblasting descaling product surface. For stainless steel products, we use acid to remove surface oil and impurities.
3. How do you ensure the quality of products?
Thanks for your question.Our production staff is trained through national quality department, and obtain the corresponding certificate, with years of production and design experience. Weld must undergo X-ray inspection to ensure that no defects.
4. Can you help us matching related products?
Thanks for your question. Our company also is surrounded by a lot of ancillary businesses, such as flanges, boiler, oil refining equipment, etc. We can help you matching the highest quality products with the lowest prices .
Product Highlights
Dish tank head for impianti completi per la tintura e l’essiccazione dei filati We manufacture a wide range of vessel heads to works standards, both for construction purposes and as dished vessel heads in the form of torispherical heads, elliptical heads and caps for pressure applications. ...
Oil Tank Stainless Steel Dish Head
Product Description: Stainless Steel Dish Head is made of stainless steel materials, including 304, 304L and 316. It has high weldability and good formability. It can be designed to have different weights and pressures. The dish head comes in various shapes, such as hemispherical, elliptical and ...
Customizable Hemispherical Tank Head For Pressure Vessel
Product Description: Hemispherical Heads for Pressure Vessel Hemispherical heads, also known as hemi heads, are a type of formed head that are commonly used for pressure vessels. These heads have a curved shape that resembles a half-sphere, which gives them a high level of strength and durability. ...
300mm Welding Semi Elliptical Head
5372 Diameter Carbon Steel Semi Elliptical Heads For Shell And Tube Heat Exchangers Product Description: Semi Elliptical Head Semi Elliptical Head is a kind of vessel dished head or dished tank head with an elliptical shape. It is widely used in a variety of industries, such as power, oil, gas, and ...
Carbon Steel Hot Formed Semi Ellipsoidal Tank Heads 2:1
Carbon Steel Hot Formed Semi Ellipsoidal 2:1 Tank Heads Description of tank heads GLM specializes in ASME 2:1 elliptical heads and weld caps. We also manufacture dished only, hemispherical, torisperical head ,sperical head, flat head, cones and sperical tanks heads. Specifications of Semi Ellipsodid...
