Carbon Steel Conical Tank Heads For Vessel Bottom Or Cover Plates
Product Details
| Head Code: | Conical Tank Heads | Diameter: | 3800 |
|---|---|---|---|
| Shape:: | Equal | Material: | Carbon Steel |
| Standard:: | ANSI, ASME ,MSS, API, DIN, JIS, BS. AWWA And GB | Usage:: | Convey Water, Oil, Gas, Steam And So On |
| Highlight |
Carbon Steel Conical Tank Heads,Vessel Bottom Conical Tank Heads,Cover Plates Dished Tank Heads |
||
Product Description
Carbon steel conical tank heads for vessel bottom or cover plates
The conical head is applied for the bottom of the pressure vessel to facilitate the collection and removal of internal materials and for the connection of two-stage vessels of varying diameters
Technical characteristics
A conical head is generally specified by following factors :
Big Diameter , Small Diameter , Bottom angle, Knuckle radius or
Big Diameter , Small Diameter , Height, Knuckle radius .
For 15°cones : Possibility to realize it without welding seams
Possible knuckle radius value if edging machining :
4 – 15 – 30 – 50 – 75 – 100 – 125 – 150 – 200 …
Possible knuckle radius value if embossing process:
5 – 10 – 15 – 20 – 30 – 50 – …
Specifications:
| Brand Name: | GLM |
| Diameter: | 89mm--10000mm |
| Thickness: | 2mm--300mm |
| Reduction Ratio: | about 10% |
| Material: | Carbon Steel, Stainless Steel, Duplex, Super Duplex, Aluminum, Nickel and Nickel Alloys, Copper and Copper Alloys, Titanium and Its Alloys, Zirconium and all cladded material combinations. |
| Forming method: | Hot forming,cold forming |
| Surface Treatment: | Sand Blasting,Pickling,oil,discaling |
| Inspection: | UT,RT,MT,PT,TOFD. |
| Applicable Standard: | ASME ,PED and GB |
| Certificate: | ISO9001,ISO45001,OHSAS18001 |
| Applications: |
Such as oil, chemical industry, water conservancy, electric power, boiler, machinery, metallurgy, sanitary construction etc. |
| Package: | Wooden cases ,wooden pallet,Steel pallet or as per customers requirement |
| Customized Product: | Available |
producing-process mode
