Home ProductsStainless Steel Dish Head

SS304L 300mm Dished Heads For Tanks End Forming Hot Pressing For Boiler OEM

Certification
China Wuhan Linmei Head Plate Co., Ltd. certification
China Wuhan Linmei Head Plate Co., Ltd. certification
I'm Online Chat Now

SS304L 300mm Dished Heads For Tanks End Forming Hot Pressing For Boiler OEM

SS304L 300mm Dished Heads For Tanks End Forming Hot Pressing For Boiler OEM
SS304L 300mm Dished Heads For Tanks End Forming Hot Pressing For Boiler OEM

Large Image :  SS304L 300mm Dished Heads For Tanks End Forming Hot Pressing For Boiler OEM

Product Details:
Place of Origin: China
Brand Name: GLM
Certification: ASME, PED and GB
Model Number: CAP
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: $5.00 - $125.00
Packaging Details: wooden box and iron shelf or as percustomers requirement
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 50000

SS304L 300mm Dished Heads For Tanks End Forming Hot Pressing For Boiler OEM

Description
Material: Stainless Steel Thickness:: 2mm–300mm
Diameter: 89mm–10000mm Technics:: Forged
Product Name: Stainless Steel Dish Head Standard: ASME, PED And GB
High Light:

SS304L dished heads for tanks

,

300mm dished heads for tanks

,

dish end forming Hot pressing OEM

Stainless Steel Elliptical Head/Dished Heads End Tank Head /Tube End For Boiler Pressure Container


Diameter 500mm-8000mm stainless steel torispherical dished head is used for all kinds of tanks and pressure vessel,which is made with stainless steel. These torispherical dished heads are cold processed or hot-formed, seamless and stress treated. These torispherical dished heads are widely used in industrial storage or pressure vessels such as storage tanks, heat exchangers, towers, reactors, boilers and separations equipment. Our high quality and innovative vessel heads include elliptical head, torispherical head, hemispherical head and conical head, etc. STRENGTH Equipments had been supplying ASME certificated dished heads at a competitive factory price.


Description:
Dished end, also called dished head or tank head, is an important pressure element for pressure vessels and boilers. The dished end is usually used at both ends of the pressure vessel and welded with the cylinder. According to the different geometric shapes, it can be divided into elliptical tank head, torispherical end, hemispherical dish end, spherical end, conical end, flat end, etc. High pressure vessels and boiler heads are mostly hemispherical, and elliptical are used for medium pressure and only a small number of low pressure vessels use torispherical.


Specifications:

Brand Name: GLM
Diameter: 89mm-10000mm
Thickness: 2mm--300mm
Reduction Ratio: About 10%
Material: Duplex steel,carbon steel,stainless steel,aluminum,titanium and etc.
Technology: Hot pressing, Cold pressing
Surface Treatment: Sand Blasting,Pickling
Test: UT,RT,MT,PT,TOFD.
Applicable Standard: ASME, PED and GB
Certificate: ISO9001 ,ISO45001,OHSAS18001
Applications: Petroleum, chemical industry, water conservancy, electric power,boiler, machinery, metallurgy, sanitary construction etc.
Packaging: wooden box and iron shelf or as percustomers requirement
Customized Product Support

 Item Types
SS304L 300mm Dished Heads For Tanks End Forming Hot Pressing For Boiler OEM 0


Products

SS304L 300mm Dished Heads For Tanks End Forming Hot Pressing For Boiler OEM 1


Packing & Delivery
SS304L 300mm Dished Heads For Tanks End Forming Hot Pressing For Boiler OEM 2


Applications:


SS304L 300mm Dished Heads For Tanks End Forming Hot Pressing For Boiler OEM 3


FAQ:

1. What’s the information should I provide when inquiry?

Thanks for your question. If you have drawings, we will be entirely in accordance with production drawings . If you do not have the drawing, you can tell me the product data. There are several important data, such as material, type of head( We have elliptical head, hemispherical head, dished head, flat head, etc. ),diameter, thickness, special tolerances or requirements. We can do the drawings according to your requirements, and you confirm that the final product drawings.



2. what are surface treatment of the product?

Thanks for your question. For carbon steel products, we sandblasting descaling product surface. For stainless steel products, we use acid to remove surface oil and impurities.



3. How do you ensure the quality of products?

Thanks for your question.Our production staff is trained through national quality department, and obtain the corresponding certificate, with years of production and design experience. Weld must undergo X-ray inspection to ensure that no defects.



4. Can you help us matching related products?

Thanks for your question. Our company also is surrounded by a lot of ancillary businesses, such as flanges, boiler, oil refining equipment, etc. We can help you matching the highest quality products with the lowest prices.
