Product Details:
Place of Origin: China
Brand Name: GLM
Certification: ASME, PED and GB
Model Number: CAP
Payment & Shipping Terms:
Minimum Order Quantity: 1
Packaging Details: wooden box and iron shelf or as percustomers requirement
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram

304H Oval Ellipsoidal Dished Head Standard Flanged And Dished Head Dimensions

Description
Body Material: 304H/304L ASTM A182 F316 Head Code: Elliptical Dish Head
Technology: Hot Pressing/cold Pressing Surface Treatment: Pickling
Package: Plywood Cases Or Pallets Application: Power Station, Boiler, Industrial
High Light:

304H ellipsoidal dished head

,

ASTM A182 ellipsoidal dished head

,

PED stainless steel dished ends

Closing Steel Oval Elliptical Dish Head For Atmospheric Tank



A 2:1 elliptical tank head is fabricated to have a certain shape instead of a particular dish radius or knuckle radius. The dish radius is approximately 90% of the diameter and the knuckle radius is approximately 17% of the diameter. 2:1 elliptical flanged and dished heads are ASME compliant.



Defining Features

- Inspected for compliance by an ASME Authorized Inspector

- Higher volume than other head shapes at the same diameter

- Useful for moderate to high pressure applications





Feature:
Polishing for sanitary applications and aesthetic appeal
Built to match your production processes and techniques
Useful for moderate to high-pressure applications
Bevel, taper, and landing zone weld preparation available
Assembly with heat transfer can be provided



Specifications:



Brand Name: GLM
Diameter: 89mm--10000mm
Thickness: 2mm--300mm
Reduction Ratio: about 10%
Material: Carbon Steel, Stainless Steel, Duplex, Super Duplex, Aluminum, Nickel and Nickel Alloys, Copper and Copper Alloys, Titanium and Its Alloys, Zirconium and all cladded material combinations.
Forming method: Hot forming,cold forming
Surface Treatment: Sand Blasting,Pickling,oil,discaling
Inspection: UT,RT,MT,PT,TOFD.
Applicable Standard: ASME ,PED and GB
Certificate: ISO9001,ISO45001,OHSAS18001
Applications:

Such as oil, chemical industry, water conservancy, electric power,

boiler, machinery, metallurgy, sanitary construction etc.

Package: Wooden cases ,wooden pallet,Steel pallet or as per customers requirement
Customized Product: Available





Products

304H Oval Ellipsoidal Dished Head Standard Flanged And Dished Head Dimensions 0304H Oval Ellipsoidal Dished Head Standard Flanged And Dished Head Dimensions 1

304H Oval Ellipsoidal Dished Head Standard Flanged And Dished Head Dimensions 2





FAQ:

1. What’s the information should I provide when inquiry?

Thanks for your question. If you have drawings, we will be entirely in accordance with production drawings . If you do not have the drawing, you can tell me the product data. There are several important data, such as material, type of head( We have elliptical head, hemispherical head, dished head, flat head, etc. ),diameter, thickness, special tolerances or requirements. We can do the drawings according to your requirements, and you confirm that the final product drawings.



2. what are surface treatment of the product?

Thanks for your question. For carbon steel products, we sandblasting descaling product surface. For stainless steel products, we use acid to remove surface oil and impurities.



3. How do you ensure the quality of products?

Thanks for your question.Our production staff is trained through national quality department, and obtain the corresponding certificate, with years of production and design experience. Weld must undergo X-ray inspection to ensure that no defects.



4. Can you help us matching related products?

Thanks for your question. Our company also is surrounded by a lot of ancillary businesses, such as flanges, boiler, oil refining equipment, etc. We can help you matching the highest quality products with the lowest prices.
