Pressure Vessel 89mm Flat Dished Head For Elliptical Bottoms 316L Stainless Steel

Certification
China Wuhan Linmei Head Plate Co., Ltd. certification
China Wuhan Linmei Head Plate Co., Ltd. certification
I'm Online Chat Now

Pressure Vessel 89mm Flat Dished Head For Elliptical Bottoms 316L Stainless Steel

Pressure Vessel 89mm Flat Dished Head For Elliptical Bottoms 316L Stainless Steel
Pressure Vessel 89mm Flat Dished Head For Elliptical Bottoms 316L Stainless Steel

Large Image :  Pressure Vessel 89mm Flat Dished Head For Elliptical Bottoms 316L Stainless Steel

Product Details:
Place of Origin: China
Brand Name: GLM
Certification: ASME, PED and GB
Model Number: CAP
Payment & Shipping Terms:
Minimum Order Quantity: 1
Packaging Details: wooden box and iron shelf or as percustomers requirement
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 50000

Pressure Vessel 89mm Flat Dished Head For Elliptical Bottoms 316L Stainless Steel

Description
General: Pressure Vessel Dish End Material: Duplex Steel,Claded Steel
Shape: Pressure Vessel Head Feature: Excellent Quality, Fine Finishing
Application: Caping Pipe Name: Flat Dished Head
Surface Treatment: Sand Blasting,Pickling,oil,discaling Delivery Time: 20 Days After Receiving The Down Payment
High Light:

89mm Flat Dished Head

,

Flat Dished Head for Elliptical Bottoms

,

316L stainless steel dish head

Pressure Vessel Dish End Elliptical Bottoms Pipe Propane Tank Head For Boilers





What is Mean By Pressure Vessels Heads :



It is major Part of Pressure Vessel which closes ends of the cylindrical section or shell of the pressure vessel is called as Pressure Vessels Heads. There are various common names are used for Pressure Vessels Heads which are Dish Ends, Formed Heads, End Closure, End Caps, Vessel Ends, Vessel Caps etc. but most Common name is Dish ends.



Types of Pressure Vessels Heads :

There are four basic types of pressure vessels heads or Dish ends is most widely used in fabrication of Pressure Vessels.

Flat Heads

Ellipsoidal Heads

Toripherical Heads or Flange and Dished Heads

Hemipherical Heads



Specifications:



Brand Name: GLM
Diameter: 89mm--10000mm
Thickness: 2mm--300mm
Reduction Ratio: about 10%
Material: Carbon Steel, Stainless Steel, Duplex, Super Duplex, Aluminum, Nickel and Nickel Alloys, Copper and Copper Alloys, Titanium and Its Alloys, Zirconium and all cladded material combinations.
Forming method: Hot forming,cold forming
Surface Treatment: Sand Blasting,Pickling,oil,discaling
Inspection: UT,RT,MT,PT,TOFD.
Applicable Standard: ASME ,PED and GB
Certificate: ISO9001,ISO45001,OHSAS18001
Applications:

Such as oil, chemical industry, water conservancy, electric power,

boiler, machinery, metallurgy, sanitary construction etc.

Package: Wooden cases ,wooden pallet,Steel pallet or as per customers requirement
Customized Product: Available





Product Display



Pressure Vessel 89mm Flat Dished Head For Elliptical Bottoms 316L Stainless Steel 0

Pressure Vessel 89mm Flat Dished Head For Elliptical Bottoms 316L Stainless Steel 1

Pressure Vessel 89mm Flat Dished Head For Elliptical Bottoms 316L Stainless Steel 2

Pressure Vessel 89mm Flat Dished Head For Elliptical Bottoms 316L Stainless Steel 3



Recommended by seller

Pressure Vessel 89mm Flat Dished Head For Elliptical Bottoms 316L Stainless Steel 4

Pressure Vessel 89mm Flat Dished Head For Elliptical Bottoms 316L Stainless Steel 5



FAQ:

1. What’s the information should I provide when inquiry?

Thanks for your question. If you have drawings, we will be entirely in accordance with production drawings . If you do not have the drawing, you can tell me the product data. There are several important data, such as material, type of head( We have elliptical head, hemispherical head, dished head, flat head, etc. ),diameter, thickness, special tolerances or requirements. We can do the drawings according to your requirements, and you confirm that the final product drawings.



2. what are surface treatment of the product?

Thanks for your question. For carbon steel products, we sandblasting descaling product surface. For stainless steel products, we use acid to remove surface oil and impurities.



3. How do you ensure the quality of products?

Thanks for your question.Our production staff is trained through national quality department, and obtain the corresponding certificate, with years of production and design experience. Weld must undergo X-ray inspection to ensure that no defects.



4. Can you help us matching related products?

Thanks for your question. Our company also is surrounded by a lot of ancillary businesses, such as flanges, boiler, oil refining equipment, etc. We can help you matching the highest quality products with the lowest prices.
