SA516 Gr70 300mm Semi Ellipsoidal Dish End Head Dimensions Hot Forming 89mm
Product Details
| General: | Dished Head | Material: | SA 516 Gr70,Inconel, Hastalloy |
|---|---|---|---|
| Shape: | Dish End | Color: | Black |
| Surface Treatment: | Sand Blasting | Delivery Time: | 20 Days After Receiving The Down Payment |
| Highlight |
SA516 Gr70 Ellipsoidal Dish End,300mm Ellipsoidal Dish End Hot Forming,semi ellipsoidal head dimensions 89mm |
||
Product Description
Customized Large Size PED Hot Forming Horizontal Dished Head SA 516 Gr70 Dish End
Description
For mould pressing we could produce up to 6,100mm in diameter and thickness up to 300mm; as to spinning, diameter up to 10,000mm and thickness up to 50mm, which is for elliptical, hemispherical, torispherical, conical, flat and spherical head in different kinds of material, like carbon steel, stainless steel, Alu, Ni & Ni Alloys, Cu & Cu Alloys, Ti & Ti Alloys, Zi and all cladded material combinations.
All dished-end are contrived by point press method in cold form which is as follows :
- 2:1 Ellipsoidal.
- Tori-Spherical.
- Deep Tori-Spherical.
- Flat Bottom.
- Hemispherical.
- Crown & Petal Construction.
- Floating Heads.
Scope of work
- Supply on Job-work (FIM).
- Blank preparation with X-ray quality welding.
- Cold & hot forming.
- Intermediate & Final Stage Heat treatments.
- Crown & Petal Construction.
Specifications:
| Brand Name: | GLM |
| Diameter: | 89mm--10000mm |
| Thickness: | 2mm--300mm |
| Reduction Ratio: | about 10% |
| Material: | Carbon Steel, Stainless Steel, Duplex, Super Duplex, Aluminum, Nickel and Nickel Alloys, Copper and Copper Alloys, Titanium and Its Alloys, Zirconium and all cladded material combinations. |
| Forming method: | Hot forming,cold forming |
| Surface Treatment: | Sand Blasting,Pickling,oil,discaling |
| Inspection: | UT,RT,MT,PT,TOFD. |
| Applicable Standard: | ASME ,PED and GB |
| Certificate: | ISO9001,ISO45001,OHSAS18001 |
| Applications: |
Such as oil, chemical industry, water conservancy, electric power, boiler, machinery, metallurgy, sanitary construction etc. |
| Package: | Wooden cases ,wooden pallet,Steel pallet or as per customers requirement |
| Customized Product: | Available |
Product Display
