SA516 GR60 Pressure Vessel End Cap Pipe Fittings Conical Dish Head 300mm
Product Details
| Head Code: | SA/A516 GR 60/65/70N SA/A 283,285 | Technology: | Hot Pressing,cold Pressing |
|---|---|---|---|
| Testing: | 100% DPT, Ut & Rt Of Weld Joint | Welding: | X-ray |
| Port: | Wuhan Or Shanghai Port | Keywords: | Carbon Steel Conical Head |
| Highlight |
SA516 pressure vessel end cap,GR60 pressure vessel end cap,Pipe Fittings conical dish head 300mm |
||
Product Description
Pipe and Fittings Rolling Conical Shape Head for Water Tanks
Product Description
The Conical Head also known as the cone shell, is a kind of head shaped by stamping and hot formed, the shaped like a vertebral body . It is generally divided into conical head with flanged edge and conical head without flanged edge.Because the shape of the conical head is not complicated .So the manufacture of conical head is relatively simple.It has a special parameter which is the cone Angle.The conical head has the advantage of being easy to collect and write out the solid materials.It is often used in various pressure vessels and pressure pipelines, and it is generally suitable for atmospheric pressure equipment, as well as in the link transition between two pieces of cylinder with different diameters.
Conical head of quality is directly related to the long-term safe operation of the pressure vessel.
Classification of head
Ellipsoidal Head, Hemispherical Head and Torispherical Head are three types of ASME Pressure Vessel Dished Heads.
ELLIPSOIDAL HEAD
This is also called a 2:1 elliptical head. The shape of this head is more economical, because the height of the head is just a quarter of the diameter. Its radius varies between the major and minor axis.
HEMISPHERICAL HEAD
A sphere is the ideal shape for a head, because the pressure in the vessel is divided equally across the surface of the head. The radius (R) of the head equals the radius of the cylindrical part of the vessel.
Specifications
| Brand Name: | GLM |
| Diameter: | 89mm--10000mm |
| Thickness: | 2mm--300mm |
| Reduction Ratio: | about 10% |
| Material: | Carbon Steel, Stainless Steel, Duplex, Super Duplex, Aluminum, Nickel and Nickel Alloys, Copper and Copper Alloys, Titanium and Its Alloys, Zirconium and all cladded material combinations. |
| Forming method: | Hot forming,cold forming |
| Surface Treatment: | Sand Blasting,Pickling,oil,discaling |
| Inspection: | UT,RT,MT,PT,TOFD. |
| Applicable Standard: | ASME ,PED and GB |
| Certificate: | ISO9001,ISO45001,OHSAS18001 |
| Applications: |
Such as oil, chemical industry, water conservancy, electric power, boiler, machinery, metallurgy, sanitary construction etc. |
| Package: | Wooden cases ,wooden pallet,Steel pallet or as per customers requirement |
| Customized Product: | Available |
Product Image
