300MM 10000mm GB Asme Elliptical Head Dimensions Semi Ellipsoidal For Storage Tank
Product Details
| Material: | Carbon Steel /Stainless Steel | Thickness:: | 2mm–300mm |
|---|---|---|---|
| Surface Treatment: | Sand Blasting And Pickling | Application: | Pressure Vessel Or Tank |
| Highlight |
300mm asme elliptical head dimensions,GB asme elliptical head dimensions,10000mm semi ellipsoidal head |
||
Product Description
Dished Head for Pressure Vessel Storage Tank form China with ASME PED Approved
Description:
Dished head (also called tank en'ds, vessel head) is the end caps on a cylindrical shaped pressure vessel which is made with carbon steel, stainless steel and other alloy steel. The Pressure Vessel Head is cold processed or hot-formed, seamless and stress treated, these tank heads are widely used in industrial storage or pressure vessels such as storage tanks, heat exchangers, towers, reactors, boilers and separations equipment. Our high quality and innovative vessel head includes elliptical head, torispherical head, hemispherical head and conical head, etc. Wuhan Linmei had been supplying ASME certificated dished heads at a competitive factory price.
The elliptical head ( or named ellipsoidal head ) which is a head consisting of two parts: a rotating ellipsoidal sphere and a cylindrical straight section. Elliptical tank head is fabricated to have a certain shape instead of a particular dish radius or knuckle radius. The dish radius is approximately 90% of the diameter and the knuckle radius is approximately 17% of the diameter. 2:1 elliptical flanged and dished heads are ASME compliant.
Specifications:
| Brand Name | GLM |
| Diameter | 89mm--10000mm |
| Thickness | 2mm--300mm |
| Reduction Ratio | about 10% |
| Material | Carbon Steel, Stainless Steel, Duplex, Super Duplex, Aluminum, Nickel and Nickel Alloys, Copper and Copper Alloys, Titanium and Its Alloys, Zirconium and all cladded material combinations. |
| Forming method | Hot forming,cold forming |
| Surface Treatment | Sand Blasting,Pickling,oil,discaling |
| Inspection | UT,RT,MT,PT,TOFD. |
| Applicable Standard | ASME ,PED and GB |
| Certificate | ISO9001,ISO45001,OHSAS18001 |
| Applications | Such as oil, chemical industry, water conservancy, electric power, |
| boiler, machinery, metallurgy, sanitary construction etc. | |
| Wooden cases ,wooden pallet,Steel pallet or as per customers requirement | |
| Package: | Available |
Products
Cusomer Photos & Exhibition
Application
FAQ:
1. What’s the information should I provide when inquiry?
Thanks for your question. If you have drawings, we will be entirely in accordance with production drawings . If you do not have the drawing, you can tell me the product data. There are several important data, such as material, type of head( We have elliptical head, hemispherical head, dished head, flat head, etc. ),diameter, thickness, special tolerances or requirements. We can do the drawings according to your requirements, and you confirm that the final product drawings.
2. what are surface treatment of the product?
Thanks for your question. For carbon steel products, we sandblasting descaling product surface. For stainless steel products, we use acid to remove surface oil and impurities.
3. How do you ensure the quality of products?
Thanks for your question.Our production staff is trained through national quality department, and obtain the corresponding certificate, with years of production and design experience. Weld must undergo X-ray inspection to ensure that no defects.
4. Can you help us matching related products?
Thanks for your question. Our company also is surrounded by a lot of ancillary businesses, such as flanges, boiler, oil refining equipment, etc. We can help you matching the highest quality products with the lowest prices.
