Product Details:
|
| Head Code: | Spherical Head | Technology: | Hot Pressing,cold Pressing |
|---|---|---|---|
| Reduction Ratio:: | About 10% | Certificate: | ISO9001 ,ISO14001,OHSAS18001 |
| High Light: | ASME 2 To 1 Spherical Heads,SS304 Spherical Heads,elliptical dish end domes Head PED |
||
Large Diameter spherical Segmental Dish Domes Heads segmented dish head For Boiler Parts pressure vessels
Product Description
We specialize in the exotic material/ special shaped/ super-thickness/ ultra heavy heads fabrication of conventional tank heads, carbon, alloy, and low alloy steels, stainless clad, titanium, nickel, aluminum, etc. Our products are primarily intended for pressure vessels, tanks, and boilers, and manufactured to all applicable GB, ASME, DIN standards. The tank heads can be fabricated in configurations such as, dished orelliptical heads, spherical heads, torispherical heads, conical heads, flat bottom heads, or ASME 2:1 semi elliptical.
Spherical head Product Image
Specifications:
| Brand Name: | GLM |
| Diameter: | 89mm--10000mm |
| Thickness: | 2mm--300mm |
| Reduction Ratio: | about 10% |
| Material: | Carbon Steel, Stainless Steel, Duplex, Super Duplex, Aluminum, Nickel and Nickel Alloys, Copper and Copper Alloys, Titanium and Its Alloys, Zirconium and all cladded material combinations. |
| Forming method: | Hot forming,cold forming |
| Surface Treatment: | Sand Blasting,Pickling,oil,discaling |
| Inspection: | UT,RT,MT,PT,TOFD. |
| Applicable Standard: | ASME ,PED and GB |
| Certificate: | ISO9001,ISO45001,OHSAS18001 |
| Applications: |
Such as oil, chemical industry, water conservancy, electric power, boiler, machinery, metallurgy, sanitary construction etc. |
| Package: | Wooden cases ,wooden pallet,Steel pallet or as per customers requirement |
| Customized Product: | Available |
Scope of application
Unlike an elliptical workpiece, a spherical head does not require flanging. This is why spherical heads can be used in the internal structures of pipelines. Besides that, they are widely used in pharmaceutics, power industry; and chemical and food processing industries.
Also, the spherical composition of products allows using them in architecture and design, improvement of household plots, and other areas. Non-flanged metal products are elements of cylindrical vessels and machines operating under low pressure or filling vessels (filter presses, fuel tanks, accumulators, tank trucks, etc.).
Packing and Delivery
Pallet packing, wooden case packing, steel pallet packing, nude packing, according to customers' requirement.
